种类与百科/Brief Introduction：

这个机器是溶液生产制造线中的罐装旋（轧）盖设备，最主要的适用玻璃窗瓶并且塑料件瓶的罐装、上盖、塑封。进行渐渐式并且圆球产品定位式罐装，电磁能噪声送盖，全主动旋（轧）盖，体现了无瓶不灌效果。这个机器罐装和旋（轧）盖合二为一，设置高级，空间结构密集，基本具有GMP规则。It’s a major machine in production line for  liquid, it main used in filling, capping placing and sealing of all kinds of bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

亮点/Characteristic：

◆任何电子产品器件均应用知名度高口碑好产品。All elements is well know brand.◆远程服务器使用形象简便，无瓶不包装，计量检验*。Direct viewing operation, no bottle nofilling, measuring accurate.◆全会自动旋（轧）盖，保证质量密封的牢固性、美感。Automatic sealing, ensure firm and beauty.◆彻底决定GMP规定加工制作。The whole machine is designed according to the requirements of GMP.

系统技术参数表/Technical Parameters：

支持外形尺寸Filling Volume	30-500ml
工作效率Productivity	20-50瓶/分    60-100瓶/分 20-🔯50bottles/min    60-100bottles/min
灌装生产线准确度Filling Precision	≤±1%
电源线Power Supply	380V/50Hz
旋（轧）盖率Capping Rate	≥98%
瓦数Power	2.5Kw
机子重量 Weight	550 kg
外表尺寸Dimension	1800*900*1600mm
