的主要用途与间介/Brief Introduction：

机械主要包括非常规三通接头罐装阀，适于于水剂和膏霜类种产品的罐装，尤为对高凝固点原辅料（如浓酱、干辣椒酱、番茄酱、种衣剂、微乳剂、透明桌面剂等）的使用效果是比较明显的，且误差高。机械主要包括PLC可程序编写把控好，配合69英寸触屏屏电脑用户界面软件系统，设立定时进瓶，定时罐装，定时出瓶，电器元件，自动元组成件均主要包括国外项目，加强组织领导了好品质的效率和经久安全稳定的耐腐蚀性。本仪器组成简略，运营便宜，是中国内地理想型的采取高凝固点原辅料的罐装仪器。机械添置了控制渗漏与金属金属拉丝的罐装闷头，加强组织领导罐装成功后无渗漏，无金属金属拉丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

基本特征/Characteristic：

◆操作设计软件——主要采用三凌PLC操作设计软件，装灌分子量随意调整。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆方法介面——6屏幕尺寸彩屏手触式方法介面，精确性容易、平安靠普Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆效果优化——排料有防漏滴安装，可可根据货位性提供下潜灌装设备效果。（此效果可选则）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器开关电子器件——均选取国际上著名品店牌，提高认识设施设备的安会可靠的、精准的性好；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机制主件——机主件均选择上等304不锈铝生产制作,若有还要碰触原料能够 选择316L另算钱用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆记数加测——实时时间记数，对岗位出现精确性体现。Counting test, real-time, intuitive reflect the yield of work.◆灌装线测试——无瓶不灌、瓶数欠缺不灌Bottle filling test - no bottle no filling, not enough◆保障症状——远程服务器按照GMP追求，可轻轻松松取下、进行服务器维护清洁保障。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆改换外形尺寸——换灌装设备外形尺寸时，只需要十分简单变动，快些玩转信用卡。Changing specifications - change the filling specifications, simply adjust, easy fix.◆坏保运行坏境——运行坏境了坏保框架的，使工具的基本操作坏境进一步清洁环境卫生环境卫生。（此坏保运行坏境可能配搭）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技能参数值/technical parameters：

装罐头数The number of filling head	8头（待选4、6、8、10、1两个装罐头）8 head (op𝔍tional 4, 6, 8, 10, 12 filling head)
常用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
的计量准确度measure precision	±1%
罐装电容量Canned capacity	150-1000ml
生产销售特性Production Capacity	2400-4000瓶/个钟头2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
